Cloudinary provides many built-in image resizing and cropping options: filling or fitting to required dimensions, scaling image up or down, cropping to a thumbnail, and so forth. When cropping you'll need to specify an anchor, or gravity. The image crop can be anchored to the image's center, top, left, etc. The cropping can even be relative to faces detected in the image.

Occasionally, you will know the exact fixed coordinates required for the perfect crop. The most common example is when you offer your users to upload their profile pictures and allow them to manually and interactively crop the uploaded picture. This is usually done using a client-side Javascript cropping library that lets the user visually mark the rectangle to crop from the original picture.

There are many nice Javascript libraries for visual cropping to choose from. These libraries will not perform the actual cropping, but rather identify and send the user's selected absolute crop coordinates to your server for processing.

So while you already have a nice pick of client-side libraries to retrieve the crop coordinates, you still need to implement the cropping process itself, store the result and deliver it to your users.

Instead, you can now use Cloudinary as your Cloud-based interactive image cropping and delivery service. Simply pass the user’s selected coordinates to Cloudinary and it will take care of the rest.

Here's an example of cropping an uploaded image to a 300x200 rectangle starting at the 355x410 pixels corner:

.../image/upload/x_355,y_410,w_300,h_200,c_crop/brown_sheep.jpg

Same example using Cloudinary’s Ruby on Rails integration GEM:

      <%= cl_image_tag("brown_sheep.jpg",
                                      :width => 300, :height => 200,
                                      :x => 355, :y => 410, :crop => :crop) %>

You can also use the original crop coordinates to create thumbnails in different dimensions by chaining multiple transformations. The following example generates a 150x100 image with the cropped brown sheep:

.../x_355,y_410,w_300,h_200,c_crop/w_150,h_100,c_fill/brown_sheep.jpg

Same example in Ruby on Rails:

     <%= cl_image_tag(“brown_sheep.jpg”,
                                     :width => 150, :height => 100, :crop => :fill,
                                     :transformation => {
                                          :width => 300, :height => 200,
                                          :x => 355, :y => 410, :crop => :crop }) %>

Last but not least - if your website allows users to login using Facebook Connect, you probably also import the user's Facebook profile picture to be shown on your service. Many social websites also allow the users to manually crop their Facebook profile picture for just the perfect shot. Using Cloudinary and the above technique, you can retrieve and crop a Facebook profile picture in a single step, without a sweat.

The following example crops a Facebook profile picture to a 130x140 image starting at 25x10:

.../image/facebook/w_130,h_140,c_crop,x_25,y_10/zuck.jpg

For more details on custom coordinates cropping and image transformations in general, see our documentation.

Don’t have a Cloudinary account? Sign up to our free plan and start cropping your images in the Cloud.

When we set to develop Cloudinary’s Rails integration Gem, it was obvious to us that we’ll base it on CarrierWave. Here’s why.

Photos are a major part of your website. Your eCommerce solution will have multiple snapshots uploaded for each product. Your users might want to upload their photo to be used as their personal profile photo. What’s entailed when developing such a photo management pipeline, end-to-end?

• You’ll need an HTML file upload form.
• The server will need to manage the reception and processing of the uploaded image files.
• Uploaded images should be stored on a safe storage with access for multiple application servers.
• Model entities should keep references to uploaded images.
• Uploaded images will need to be resized and cropped into different dimensions matching the graphics design of your web site.
• The server will need to find and deliver the resized images to visitors of your site when displaying a page with the relevant model entity (e.g., display a thumbnail of the profile picture in a user profile page, etc.).
• Allow overriding uploaded images with new ones when needed.

Over the years, we’ve had the pleasure of using some of RoR’s many excellent file upload solutions: CarrierWave, Paperclip, Dragonfly, attachment_fu and others. All-in-all, CarrierWave often proved a better fit for our needs:

• The storage engine is Cloudinary. All images uploaded through CarrierWave model methods are directly uploaded and stored in the cloud.
• All resized versions and image transformations are done in the cloud by Cloudinary:
• No need to install any image processing tools or Ruby GEMs.
• You can create the resized versions eagerly while uploading or lazily when users accesses the actual images. Save processing time and storage.
• Change your desired image versions at any time and Cloudinary will just create them on the fly, no need to batch update all your images when the graphics design of your site changes.
• All public image URLs returned by CarrierWave are Cloudinary URLs. This means they are automatically delivered through a global CDN with smart caching. Seamlessly enhancing the performance of your web application.

class PictureUploader < CarrierWave::Uploader::Base

  include Cloudinary::CarrierWave

  version :standard do
    process :resize_to_fill => [100, 150, :north]
  end

  version :thumbnail do
    process :resize_to_fit => [50, 50]
  end

end

class Post < ActiveRecord::Base
  ...
  mount_uploader :picture, PictureUploader
  ...
end

= form_for(:post) do |post_form|
  = post_form.hidden_field(:picture_cache)
  = post_form.file_field(:picture)

= image_tag(post.picture_url, :alt => post.short_name)

= image_tag(post.picture_url(:thumbnail), :width => 50, :height => 50)

We believe that for Ruby on Rails developers, the combination of Cloudinary with its CarrierWave-based gem, delivers a complete image management solution, with excellent model binding.

More details about about our CarrierWave plugin are available in our documentation: http://cloudinary.com/documentation/rails_integration#carrierwave_upload

What do you think about our solution? any suggestions or improvement ideas?

UPDATE: We've published another post about additional advanced image transformations in the cloud with CarrierWave & Cloudinary.

Cloudinary’s roots go back to when we needed to embed users’ uploaded images and profile pictures for web projects we’ve developed.

We had to show people and faces of users in various dimensions and perspectives, and the process proved cumbersome.

These days, Cloudinary allows you to easily resize and crop your images to snugly fit the graphics design. But sometimes, just resizing pictures using ‘fill’ crop and ‘center’ gravity just doesn’t cut it. This is a common problem with user profile photos.

So we thought it is about time we add some more brainpower into the cropping process. Of-course we could just let the users manually crop their own profile pictures, but that just wasn’t fun enough :)

We decided to add face detection based cropping. Facebook use it internally to find faces of users and crop the profile pictures accordingly. Google does it as well. What about the rest of us?

Fortunately, we didn’t need to invent the wheel. Some top-notch face detection open source algorithms are freely available today. They are just not production ready or easy to integrate. The good news - we did the heavy lifting for you. We integrated existing tools and libraries, optimized their settings and added smart face detection based cropping to Cloudinary. Try it out - you won’t believe the difference that it makes.

Cloudinary supports either a single face detection or multiple faces detection (i.e., focusing on the people in a picture). You can easily create a face thumbnail of your users, crop an image to focus on a person or resize an image to fill the required dimensions while making sure the person in the original picture appears in the resized version of the image. And as usual, Cloudinary does all this automatically for you in the cloud and delivers the images through a fast CDN.

Using face detection based cropping with Cloudinary is very simple. Below are examples showing both cropping via our universal dynamic URLs and our Ruby on Rails integration.

http://res.cloudinary.com/demo/image/upload/w_100,h_100,c_thumb,g_face/face_top.jpg

<%= cl_image_tag("face_top.jpg", :width =>100, :height => 100,
:crop => :thumb, :gravity => :face) %>

For more details and usage examples, take a look at our documentation: http://cloudinary.com/documentation/image_transformations#face_detection

This feature is now available across all our plans, including the free one. We hope you like it.
